Non-Standard Precision Mechanical Parts Processing Skills And Precautions

In the processing and production of non-standard precision mechanical parts in mechanical processing plants,although there are many tips that are not obvious,but if you can know and master these tips,it will make you more efficient!Here we introduce a few commonly used tips in the processing of non-standard precision mechanical parts,let everyone understand together:

1,Tips commonly used in non-standard precision mechanical parts processing.It is inconvenient to use magnets to absorb small precision mechanical parts.An iron plate can be sucked under the magnet.It can not only absorb many small precision mechanical parts,but also pull the iron plate away.The small precision mechanical parts will automatically fall into the collection box,which is very practical.

2,Non-standard precision mechanical parts processing disassemble the vise jaws and process two M4 threaded holes,align two 1.5mm thick steel plates with the jaws,use aluminum rivets to rivet a hard brass plate with a thickness of 0.8mm,and fix with M4 countersunk screws onto the jaws to form a durable soft jaw.This can protect precision mechanical parts from being pinched.

3,Horizontal CNC machining.When the pulley is slipping between the pulley and the axle,you can use a ∮15-18mm dimple bit on the axle to draw a series of nests,which can form an adsorption force to prevent slipping.
